| 输出电流 | 0-50A |
| 输出电压 | 24V |
| 输出电压调整范围 | 24-28 Vdc |
| 输出功率 | 1200W |
| 线电压调整率 | ±0.5% |
| 负载调整率 | ±1% |
| 纹波电压 | < 1% Vrated pk-pk @ rated load |
| 开机时间 | 2,000 ms with AC turn on |
| 保持时间 |
16 ms @ 1000 w load, with nominal input rangeN 20 ms @800 w load, with nominal input range |
| 动态回应 |
± 5% @ 115 & 230 Vac input with 0-50% or 50-100% load change ± 10% @ 115 & 230 Vac input with 5-100% load change |
| 电容性负载启动 | 6.000 uF |
| 升压时间 | < 50 ms |
| 峰值功率 | 1,500 W peak for 3 sec, @ 180-264 Vac |
